| Item | Specification |
| Profile Processing Range of Alum. | ≤6800mm |
| Transfer Materials | Film or paper |
| Total Power | 15.7kW （380V Three-phase four-wire） |
| Heating method | The gas heating |
| Thermal Transfer Temperature | 150℃～180℃ |
| Initial Heating Time(min) | 7~15min. according to the length of alum. materials |
| Enter Furnace and temperature control model | Automatic |
| Transfer Model | Single vacuum(profile) |
| In feed Trolley | Double feed |
| Single Transfer Quantity | 36 pieces (3 level) |
| Max Single section(mm) | 200×160 |
| Transfer Material | High temperature film and transfer paper |
| Burner | Riello Brand |
| Production Capacity | 3-5Tons (as per working for 10 hours) |
| Inner Furnace Temperature Difference(℃) | ±5 |
| Reverse Blowing Time(s) | 60 |
| Furnace Surface Temperature Rise | ≤10℃ |
| Furnace Door Temperature Rise | ≤40℃ |
| Air consumption(Natural gas 8400 kcal/m3） | 7～9 m3/h |
| Construction | Combination structure, painted by light grey or yellow |
| Outside Material | δ=1.5~2.0 mm A3 steel plate |
| Inside Material | δ=1.5 mm A3 galvanized plate |
| Heat preservation | Adopt 250 mm thick and 80K high quality insulation cotton |
| Air circulation type | Down in & up back type, Air ductδ=, = 1.2mm galvanized plate hydraulic molding |
| wrap angle | 100 mm ×20 mm ×1.5 mm |
